3-WAY FULL/ REDUCED PORT BALL VALVE, 1000PSI, DIRECT MOUNTING PAD

IT-3W-H
3-WAY FULL/ REDUCED PORT BALL VALVE, 1000PSI, DIRECT MOUNTING PAD
3-WAY FULL/ REDUCED PORT BALL VALVE, 1000PSI, DIRECT MOUNTING PAD
STAINLESS STEEL & CARBON STEEL

ASTM-A351-CF8M/ EN10213 1.4408
ASTM-A351-CF8/ EN10213 1.4308
ASTM-A216-WCB/ EN10213 1.0619

  • Size:1/4”~1.1/2" / 2”
  • Rating: 1000psi/ PN63
  • Threaded end
  • L port/ T port
  • Full port or Reduced port available
  • Direct Mounting pad ISO 5211 for actuator assembling
  • Blow-out proof stem
  • Anti-static device
  • Investment casting body & cap
Alternative option:
  • Locking device
  • No mounting pad or low mounting pad available.
