1-PC WAFER TYPE BALL VALVE, DIRECT MOUNTING PAD, PN16/40

IT-111H
1-PC WAFER TYPE BALL VALVE, DIRECT MOUNTING PAD, PN16/40
1-PC WAFER TYPE BALL VALVE, DIRECT MOUNTING PAD, PN16/40
STAINLESS STEEL & CARBON STEEL

ASTM-A351-CF8M/ EN10213 1.4408
ASTM-A351-CF8/ EN10213 1.4308
ASTM-A216-WCB/ EN10213 1.0619

  • Size:1/2”~4”
  • Rating: DIN PN16/ 40
  • Flanged end
  • Full port
  • Blow-out proof stem
  • Direct mounting pad ISO 5211
  • Anti static device, Fire safe design
  • Solid ball
  • Investment casting body
  • Lever operation
Alternative option:
  • Locking device (1/2” ~ 2.1/2”)
