2-PC FULL PORT BALL VALVE, 300LBS

IT-212
2-PC FULL PORT BALL VALVE, 300LBS
2-PC FULL PORT BALL VALVE, 300LBS
STAINLESS STEEL & CARBON STEEL

ASTM-A351-CF8M/ EN10213 1.4408
ASTM-A351-CF8/ EN10213 1.4308
ASTM-A216-WCB/ EN10213 1.0619

  • Size: 1/2”~10”
  • Rating: ANSI B16.5 Class 300
  • Flanged end
  • Full port
  • Blow-out proof stem
  • Mounting pad ISO 5211
  • Anti-static device, Fire safe design
  • Investment casting body & flange
  • Solid ball
  • Casting handle: 1/2”~4”
  • Round pipe handle: 5”~10”
Alternative option:
  • Fixed handle
  • Locking handle
  •  ANSI Class 600LBS available (Different mould)
