2-PC FULL PORT BALL VALVE, PN16/40

IT-213
2-PC FULL PORT BALL VALVE, PN16/40
2-PC FULL PORT BALL VALVE, PN16/40
STAINLESS STEEL & CARBON STEEL

ASTM-A351-CF8M/ EN10213 1.4408
ASTM-A351-CF8/ EN10213 1.4308
ASTM-A216-WCB/ EN10213 1.0619

  • Size: DN15-DN300
  • Rating: EN1092-1 PN16/ 40
  • Flanged end
  • Face to face: DIN3202 F4 / F5
  • Full port
  • Blow-out proof stem
  • Mounting pad ISO 5211
  • Anti-static device, Fire safe design
  • Investment casting body & flange
  • Lever operation
Alternative option:
  • Face to face DIN3202 F1
  • Solid ball/ Hollow ball/ Welded ball
  • Wrench handle
  • Locking device
