3-PC FULL PORT BALL VALVE, 3000/ 2000PSI, DIRECT MOUNTING PAD

IT-304
3-PC FULL PORT BALL VALVE, 3000/ 2000PSI, DIRECT MOUNTING PAD
3-PC FULL PORT BALL VALVE, 3000/ 2000PSI, DIRECT MOUNTING PAD
STAINLESS STEEL & CARBON STEEL

ASTM-A351-CF8M/ EN10213 1.4408
ASTM-A351-CF8/ EN10213 1.4308
ASTM-A216-WCB/ EN10213 1.0619

  • Size: 1/4”~4”
  • Rating: 1/4”~1” 3000psi/ PN200
    1.1/4”~4” 2000psi/ PN130
  • Direct Mounting pad ISO 5211 for actuator use
  • Butt weld/ Socket weld/ Threaded end
  • Full port
  • Blow-out proof stem
  • Encapsulated body
  • Investment casting body & cap
Alternative option:
  • Locking device
  • Reduced port
  • No handle design
  • Fire Safe approval API 607
  • L length: DIN 3202 M3 standard
