3-PC FULL PORT BALL VALVE, 2000/ 1000PSI (CRYOGENIC USE)

IT-308LN
3-PC FULL PORT BALL VALVE, 2000/ 1000PSI (CRYOGENIC USE)
3-PC FULL PORT BALL VALVE, 2000/ 1000PSI (CRYOGENIC USE)
STAINLESS STEEL

ASTM-A351-CF8M/ EN10213 1.4408

  • Size:1/4”~4”
  • Cryogenic use, Working temperature for max. -196℃
  • Long neck design
  • Rating:
    1/2”~2” 2000psi/ PN130
    2-1/2”~4” 1000psi/ PN63
  • Face to Face DIN3202 M3
  • Threaded/ Socket weld/ Butt weld end
  • Full port
  • Direct Mounting pad ISO 5211
  • Blow-out proof stem, Square Stem
  • Encapsulated body
  • Investment casting body & cap
  • Anti-static design
  • With locking device
Alternative option:
  • Flanged ends available, rating AISI 150# & DIN PN16 F4
