3-WAY BALL VALVE, 150LBS, DIRECT MOUNTING PAD

IT-3W-FH
3-WAY BALL VALVE, 150LBS, DIRECT MOUNTING PAD
3-WAY BALL VALVE, 150LBS, DIRECT MOUNTING PAD
STAINLESS STEEL & CARBON STEEL

ASTM-A351-CF8M/ EN10213 1.4408
ASTM-A351-CF8/ EN10213 1.4308
ASTM-A216-WCB/ EN10213 1.0619

  • Size: 1/2”~6”
  • Rating: ANSI B 16.5 class 150
  • Flanged end
  • Full port
  • Blow-out proof stem
  • Anti-static device, Fire safe design
  • Direct mounting pad ISO 5211 for actuator assembling
  • Solid ball
  • 3-way: L port/ T port
  • Investment casting body & flange
  • Lever handle: 1/2”~4"
  • Round pipe handle: 5”~6”
Alternative option:
  • Locking handle
  • Flange DIN PN16
  • T handle design (Different mould)
  • Short face to face design (Economic type)
