SINGLE DOOR CHECK VALVE, ANSI-150/ JIS-10K/ DIN-PN16

IT-4063
SINGLE DOOR CHECK VALVE, ANSI-150/ JIS-10K/ DIN-PN16
SINGLE DOOR CHECK VALVE, ANSI-150/ JIS-10K/ DIN-PN16
STAINLESS STEEL

ASTM-A351-CF8M/ 1.4408
ASTM-A351-CF8/ 1.4308

  • Size: 2”~8” (FL-HOOK type)
  • Size: 2”~24” (SL-PIN type)
  • ANSI-150/ JIS-10K/ DIN-PN16
  • Face to Face: API-594/ API-6D
  • Design: API-594/ API-6D
  • Investment casting body
  • Inspection: API-598/ ASME-B16.34
  • To suit flanges for ISO-7005-1, ASME B16.5-150LBS, JIS B2238-10K RF
