GLOBE VALVE, FLANGED, 150LBS

IT-412
GLOBE VALVE, FLANGED, 150LBS
GLOBE VALVE, FLANGED, 150LBS
STAINLESS STEEL & CARBON STEEL

ASTM-A351-CF8M/ 1.4408
ASTM-A351-CF8/ 1.4308
ASTM-A216-WCB/ 1.0619

  • Size: 1/2”~12”
  • Flanged end
  • Rating: 150Lbs/ JIS10K
  • Face to Face: ANSI B16.10
  • End flange: ANSI B16.5
  • Design: ANSI B16.34
  • Investment casting body
  • Hand wheel operation
Alternative option:
  • Rating DIN PN16/ ANSI 300Lbs/ JIS20K
