3-PC FULL PORT SANITARY BALL VALVE
IT-S306
Stainless Steel
AISI-316 (EN10213 1.4408) (ASTM-A351-CF8M) SIZE: 1/2”~4”
- Full cavity filler seats
- Blow-out proof stem
- Investment casting body and cap
- 1000 PSI (63 BAR): 1/2”~2”
- 800 PSI (40 BAR): 2-1/2”~ 4”
- Clamp end: 3A standard, Butt Weld end
- Inside port ra≦0.4µm
Alternative Options:
- Locking device
- Butt Weld end cap: SS316L
- Non Cavity filler seat
- RJT male end
