3-PC TANK BOTTOM SANITARY BALL VALVE

IT-S33
3-PC TANK BOTTOM SANITARY BALL VALVE
3-PC TANK BOTTOM SANITARY BALL VALVE
Stainless Steel

AISI-316 (EN10213 1.4408) (ASTM-A351-CF8M) SIZE: 1”~4”

  • 3-pc body, Full port
  • Full cavity filler seats
  • Blow-out proof stem
  • Investment casting body and cap
  • 1000 PSI (63 BAR): 1”~2”
  • 800 PSI (40 BAR): 3”~ 4”
  • One side Tank Bottom end; One side Clamp end
  • Tank Bottom end : Full port tube ID, inside port ra≦0.3µm Clamp end: 3A standard, inside port ra≦0.4µm
  • Improve flow and eliminate pooling
  • Direct Mounting pad ISO 5211; Square stem
  • O-Ring stem bearing: Reduce packing side-loading and wear; Enhanced stem seal
Alternative Option
  • Locking device
  • End cap: AISI-316L
  • RJT male end, Butt weld end
  • OEM Machining upon request
